Electric Power for Serious Work
This model introduces a fully electric powertrain to the Ranger XP platform, delivering strong torque and quiet operation without sacrificing utility performance. The interior permanent magnet AC motor produces 140 lb-ft of torque and up to 110 HP peak output, providing immediate response when pulling loads, climbing slopes or accelerating with cargo.
Because electric motors deliver full torque instantly, the vehicle feels extremely responsive compared with traditional petrol or diesel side-by-sides. This makes it especially useful for towing, hauling materials or moving around farms, estates and work sites where frequent stopping and starting is common.
All-Electric Utility Performance
The lithium-ion battery system delivers up to 45 miles (around 70 km) of estimated range on a single charge. For many daily property tasks this provides enough runtime for a full day of work without needing to refuel or recharge.
Charging is handled by a factory-installed 3 kW onboard charger and a supplied Type 2 charging kit. This allows charging from standard outlets or higher capacity charging points depending on site infrastructure.
Regenerative braking captures energy when slowing down, feeding power back into the battery while helping control speed on descents. This improves efficiency while reducing wear on braking components.
Built on the Proven Ranger XP Platform
The chassis uses the Ranger XP work platform, designed to handle heavy loads and challenging terrain. With a towing capacity of 2,500 lb (1,134 kg) and a cargo box capable of carrying 1,250 lb (567 kg), it remains a serious work vehicle despite its electric drivetrain.
The Lock & Ride cargo system allows quick installation of accessories and attachments, helping adapt the machine for property maintenance, estate work, agriculture and facilities management.
Ground Clearance and Traction
Large 29-inch Pro Armor X-Terrain tyres combined with 14 inches of ground clearance allow confident travel across muddy tracks, uneven land and rough work environments. Dual A-arm suspension provides 10 inches of travel at the front and rear, helping maintain traction while carrying cargo or towing equipment.
The high-performance on-demand AWD system automatically transfers power to the wheels that need it most. VersaTrac Turf Mode allows tight turning on delicate surfaces without damaging grass or turf areas.
Practical Work Features
Several features are designed specifically for daily work tasks. A 12V power port in the cargo box allows powered accessories to run directly from the vehicle, while the Polaris Pulse electrical system provides multiple connection points for lighting, equipment and accessories.
LED headlights with integrated turn signals improve visibility in low-light conditions, while the front accent light also indicates charging status when the vehicle is plugged in.
Inside the cabin, the driver information display shows key electric system data including battery state of charge, range remaining, energy usage and charging status.
Warranty and Battery Coverage
The vehicle includes a two-year total warranty covering the machine, along with extended coverage for the electric drivetrain. The powertrain receives three years of warranty protection and the lithium-ion battery is covered for five years.
This extended coverage helps give confidence when switching to electric power for professional work environments.
Technical Specifications
| Motor Type | Interior Permanent Magnet AC Motor |
| Peak Power | 110 HP |
| Torque | 190 Nm (140 lb-ft) |
| Battery Type | Lithium-Ion |
| Battery Capacity | 14.9 kWh |
| Estimated Range | Up to 70 km (45 miles) |
| Charging System | Factory-installed 3 kW onboard charger |
| Charging Kit | Type 2 EVSE (Level 1 / Level 2 compatible) |
| Transmission | Gates Synchronous Belt H/L/N/P (Electronic Forward/Reverse) |
| Drive System | On-demand AWD / 2WD with VersaTrac Turf Mode |
| Braking System | 4-wheel hydraulic disc with regenerative braking |
| Front Suspension | Dual A-arm, 10″ (25.4 cm) travel |
| Rear Suspension | Dual A-arm IRS, 10″ (25.4 cm) travel |
| Front Tyres | 29 x 9-14 Pro Armor X-Terrain |
| Rear Tyres | 29 x 11-14 Pro Armor X-Terrain |
| Wheels | 14″ Aluminium |
| Ground Clearance | 14″ (35.5 cm) |
| Wheelbase | 81″ (206 cm) |
| Overall Dimensions (L × W × H) | 305 × 158 × 198 cm |
| Cargo Box Capacity | 567 kg (1,250 lb) |
| Towing Capacity | 1,134 kg (2,500 lb) |
| Payload Capacity | 677 kg (1,492 lb) |
| Seating Capacity | 3 persons |
| Dry Weight | 807.5 kg (1,780 lb) |
