HTA 86 Cordless Telescopic Pole Pruner: Powerful, telescopic cordless pole pruner, with a 30 cm / 12″ bar length
BUY ONLINE FROM OUR STIHL SHOP!
Powerful cordless pole pruner. Quiet and low-vibration. For professional use in tree maintenance, orchards and local authorities. For pruning trees, removing dead wood and breakage from storms, and for cutting back fruit trees. ¼” PM3 saw chain, lightweight and compact
power head with sturdy branch hook for easy removal of loose cuttings from the tree. Rigid shaft to help with guidance and a clean and
precise cut. Rapid length adjustment with quick release mechanism. Total length 270 – 390 cm.
Exterior design of STIHL guide bars are subject to change. Technical specifications remain the same.
Features
The pictures shown are sample photos. The actual appearance of the equipment features and their specific attachment to the product may differ from the pictorial representations, but will have the same functionality.
BRANCH HOOK
REMOVAL OF LOOSE CUTTINGS. Thanks to the sturdy branch hook, you can remove loose and cut branches when working at height.
EC MOTOR
LOW-MAINTENANCE AND EFFICIENT. Thanks to its compact design, low weight and high efficiency, the EC motor enables you to work in an energy efficient manner. This engine also has a long service life.
INTUITIVE OPERATION
EASY STARTING. To start the tool, all you need to do is release the lock using the locking switch. The tool can then be started using the trigger. The additional ERGO lever enables continuous work without having to restart. The self-resetting locking switch prevents accidental activation of the tool. Operation is suitable for both left-handed and right-handed users.
EXCELLENT TOOL BALANCE
REDUCES WORKING FATIGUE. Thanks to the battery’s optimal centre of gravity, this tool has a low tilting torque which supports fatigue-free working.
TELESCOPIC SHAFT WITH TWIST-SECURED CLAMPING SLEEV
EASY-TO-ADJUST SHAFT LENGTH. The square telescopic shaft is equipped with a twist-secured clamping sleeve. This enables quick and tool-free adjustment of the shaft length (may vary in overall length for different tools). This means that you can quickly and efficiently adapt the tool being used to the respective work situation.
Technical details
Rated voltage | 36 V |
Power | 0.85 kW |
Battery system | AP |
Recommended battery | AP 200 |
Weight | 4.6 kg 1) |
Bar length | 30 cm |
Bar length | 12 “ |
Saw chain pitch | 1/4” P |
IPX Rating | IPX4 |
Battery working time AP 300 S (Power level 1) | up to 68 min 2) |
Battery working time AP 500 S (Power level 1) | 0-82 min |
Battery working time AR 2000 L (Power level 1) | up to 210 min 3) |
Battery working time AR 3000 L (Power level 1) | up to 300 min 3) |
Total length (min.) | 270 cm 4) |
Total length (max.) | 390 cm 5) |
Sound pressure level | 77 dB(A) 6) |
Sound power level | 93 dB(A) 6) |
Vibration level, left | 1 m/s² 7) |
Vibration level, right | 1 m/s² 7) |
1)With bar and chain, without cable and chain oil2)Working times are approximate and may vary depending on application3)Working time may vary depending on the application4)Minimum with tool5)Maximum with tool6)K-factor according to DIR 2006/42/EC = 2.5 dB (A)7)K-factor according to DIR 2006/42/EC = 2m / s ²
