Stihl
Powered by the much-vaunted ST 600 Twin cylinder Stiga engine and boasting hydrostatic transmission, the 2240H Twin makes light work of any large lawn over 4 acres.
The102cm cutting width and Cut and Collect system makes this lawn tractor efficient, precise and easy to use
- Powered by STIGA with an ST 600 Twin cylinder engine
- 102 cm cutting width
- Smooth and easy speed control, thanks to hydrostatic drive
- Multi-function LED display
- Huge 320-litre grass collector
- Optional mulching plug and tow hitch available separately
Product details and specs
Powered by a powerful Stiga ST 600, 586cc Twin cylinder engine and possessing hydrostatic transmission, this lawn tractor is a beauty.
Twin contra-rotating blades cut and discharge clippings into the capacious rear-mounted collector in one smooth movement. It can also be used as a vacuum on your lawn to tidy up leaves in autumn! An alarm sounds when the collector is full and resets when emptied.
If you want to add vital nutrients back into the soil, simply fit the mulching plug (available as an optional extra) before mowing. This cuts the clippings even finer and discharges them back into the soil surface. This also saves time emptying the collector (not that it takes long – you can do it from the comfort of the driver’s seat.)
With seven possible blade heights and a 102cm cutting width, the actual cut and finish to your lawn are second to none. This is a hardworking lawn tractor more than capable of coping with arduous workloads.
With a handy washing link that will allow you to clean you deck quickly and efficiently you will ensure any build-up of grass and dirt on the cutting deck is removed and avoid the deck rusting.
Efficient and easy to use the 2240H is backed by a manufacturer’s five-year extended warranty. (T&C’s apply)
For advice on the ride-on best suited to your requirements please call our Technical Helpline on 01986 785272
Technical specs
General info
| EAN/UPC | 8008984851856 |
|---|---|
| SKU | 2T0970483/M22 |
Cutting system
| Cutting method | Collecting |
|---|---|
| Minimum uncut radius | 96 cm |
| Cutting width | 102 cm |
| Reverse mowing | Yes |
| Blade rotation | Timed |
| Cutting height adjustment | Manual with lever |
| Cutting height positions | 7 positions |
| Cutting height range | 30 – 90 mm |
| Number of blades | 2 |
| Blade type | Winged |
| Additional cutting method | Rear discharge, Mulching |
| Blade engagement type | Electric |
Transmission
| Transmission type | Hydrostatic |
|---|---|
| Transmission method | Pedal-operated |
Tools kit
| Mulching kit | Optional |
|---|---|
| Battery charger | Optional |
| Trailer hitch kit | Optional |
Overall dimensions
| Pack weight | 291 kg |
|---|---|
| Product length | 2550 mm |
| Product width | 1060 mm |
| Product height | 1310 mm |
| Weight | 245 kg |
Power
| Power source | Petrol |
|---|---|
| Battery capacity | 18 Ah |
| Power | 10.8 kW |
| Engine Brand | STIGA |
| Engine model | ST 600 Twin Powered by STIGA |
| Displacement | 586 cm³ |
| Engine rotation speed | 2600 rpm |
| Battery Voltage | 12 V |
| Choke | Manual |
| Engine cooling | Air |
| Fuel tank capacity | 7 l |
| Maximum working area | 4 |
Drive system
| Traction | Rear-wheel drive |
|---|
Equipment
| Collector emptying | Manual |
|---|---|
| Collector capacity | 320 l |
| Steering wheel | Mountfield ergonomic with soft grip |
| Seat type | Mountfield comfort |
| Seat adjustment | Single lever |
| Dashboard | Yes with multifunctional display |
| Front wheel size | 15×6.00-6 |
| Rear wheel size | 18×8.50-8 |
| Headlights | Conventional |
| Bumper | Yes |
| Washing link | Yes |
| Collector type | Textile |
| Storage compartment | Yes |
| Cup holder | Yes |
| Pivoting front axle | Yes |
| Antiscalp wheels | 4 |
| Safety system | Seat with Safety Contact Breaker |
Vibration and noise data
| Measured sound pressure level at operator ear dB(A) | 83.7 |
|---|---|
| Measured sound power level dB(A) | 100 |
| Guaranteed sound power level (LwA) – dB(A) | 100 |
| Max vibration on steering wheels (m/s2) | 2.84 |
| Max vibration on driver’s seat (m/s2) | 0.69 |
end cycle -->
| Engine manual | Download |
|---|---|
| Auxiliary user manual | Download |
| Additional sheet | Download |
| User manual | Download |
No accessories found. If you need something specific, email us.
